Brother LX27NT - Attachment of Needle Plate a

3 - 73
Feed unit Application of Assembly
Application Application
1-15-2 Attachment of Needle plate A
1. Set the needle plate A 1 to the needle plate B 2, and then secure it with
the 2 screws 1.
1
1
2
1 1
2
1
Screw, Pan (S/P washer)
M2.6X6
