Brother LX27NT - Attachment of Thread Guard Supporter Assy

3 - 59
Needle threading mechanism Application of Assembly
Application Application
1 Attachment of Thread guard supporter assy
1. Insert the shaft of the thread guard supporter assy 1 to the arm bed with
the screw 1.
*Key point
• There is a model without the thread guard supporter assy 1.
1
1
1
Taptite, Bind S
M4X10
