Brother LX27NT - Removal of Rear Cover Assy

2 - 5
Basic of Disassembly Main frame and Covers
Basic Basic
5 Removal of Rear cover assy
1. Pull down the presser foot lifter 1.
2. Remove the 3 screws 1, and then remove the rear cover assy 2.
→Refer to 3 - 5 of the Disassembly.
1
1 1
1
2
1
