Brother LX27NT - Removal of Accessory Table; Removal of Face Plate Assy; Removal of Pattern Selecting Dial

2 - 3
Main frame and Covers Basic of Disassembly
Basic Basic
1 Removal of Accessory table
1. Remove the accessory table 1.
1
2 Removal of Face plate assy
1. Remove the screw 1, and then remove the face plate assy 1.
→Refer to 3 - 3 of the Disassembly.
1
1
3 Removal of Pattern selecting dial
1. Pull out the pattern selecting dial 1.
1
