Brother LX27NT - Removal of Needle-Presser Module; Upper Shaft, Needle Bar and Presser Foot Unit

2 - 27
Basic of Disassembly Upper shaft, Needle bar and Presser foot unit
Basic Basic
3 Removal of Needle-presser module
1. Remove the screw 1.
2. Remove the 2 screws 2, and then remove the needle-presser module 1.
→Refer to 3 - 32 of the Disassembly.
1
1
2 2
