3 - 1

In this chapter, explains the disassembly and assembly of the each

module. When fix and replace the each module, use this chapter.

Disassembly Main frame and Covers ....................3 - 2

Main motor unit.................................3 - 6

Feed unit...........................................3 - 8

Needle threading mechanism.........3 - 19

Zigzag mechanism .........................3 - 24

Feed control mechanism ................3 - 26

Buttonhole and

Pattern selecting mechanism .........3 - 29

Upper shaft, Needle bar and

Presser foot unit .............................3 - 31

Assembly Upper shaft, Needle bar and

Presser foot unit .............................3 - 41

Buttonhole and

Pattern selecting mechanism .........3 - 51

Feed control mechanism ................3 - 53

Zigzag mechanism .........................3 - 56

Needle threading mechanism.........3 - 58

Feed unit.........................................3 - 64

Main motor unit...............................3 - 76

Main frame and Covers ..................3 - 78

Application of

Disassembly/Assembly
