Brother LX27NT User Manual

2 - 4
Main frame and Covers Basic of Disassembly
Basic Basic
4 Removal of Front cover assy
1. Remove the 2 screws 1, the screw 2 and the 2 screws 3.
2. Release the 3 hooks 1 to remove the front cover assy 2, and then
disconnect the connector 3.
→Refer to 3 - 4 of the Disassembly.
1
1
2
2
3
2
3

Brother LX27NT Specifications

General

Type	Manual sewing machine
Sewing speed	800
Stitch width	5 mm
Feed dog type	5 point
Product color	White
Buttonhole type	1 Step
Number of programs	-
Number of button holes	1
Sewing machine functions	Sewing
Automatic needle threader	Yes
Number of stitch patterns	27
Power supply type	Electric
