When repair and replace the part of the unit, refer to “CHAPTER 3:
Application of Disassembly/Assembly”.
Basic of
Disassembly/Assembly
Disassembly Main frame and Covers .............................. 2 - 2
Main motor unit........................................... 2 - 6
Feed unit .................................................... 2 - 9
Needle threading mechanism................... 2 - 12
Zigzag mechanism ................................... 2 - 14
Feed control mechanism .......................... 2 - 17
Buttonhole and
Pattern selecting mechanism ................... 2 - 21
Upper shaft, Needle bar and
Presser foot unit ....................................... 2 - 25
Assembly Upper shaft, Needle bar and
Presser foot unit ....................................... 2 - 28
Buttonhole and
Pattern selecting mechanism ................... 2 - 31
Feed control mechanism .......................... 2 - 36
Zigzag mechanism ................................... 2 - 40
Needle threading mechanism................... 2 - 44
Feed unit .................................................. 2 - 46
Main motor unit......................................... 2 - 50
Main frame and Covers ............................ 2 - 53

Brother LX27NT Specifications

General

Type	Manual sewing machine
Sewing speed	800
Stitch width	5 mm
Feed dog type	5 point
Product color	White
Buttonhole type	1 Step
Number of programs	-
Number of button holes	1
Sewing machine functions	Sewing
Automatic needle threader	Yes
Number of stitch patterns	27
Power supply type	Electric
