Brother LX27NT - Removal of Thread Guide Wire; Removal of Thread Take up Spring

3 - 21
Needle threading mechanism Application of Disassembly
Application Application
1-2 Removal of Thread guide wire
1. Remove the thread guide wire 1 from the thread guard cover assy 2.
2
1
1-3 Removal of Thread take up spring
1. Remove the spring from the thread guard cover assy 1.
1
S06
S06
