Brother LX27NT - Removal of BH Adjusting Plate

2 - 22
Buttonhole and Pattern selecting mechanism Basic of Disassembly
Basic Basic
1 Removal of BH adjusting plate
1. Remove the spring from the BH change arm 1 and the BH adjusting
plate 2.
2. Remove the screw 1, and then remove the BH adjusting plate 2.
1
S03
2
1
2
S03
