3 - 15
Application of Disassembly Feed unit
Application Application
2-12 Removal of V feed attachment
1. Release the 2 hooks 1 to remove the V feed attachment 2 from the feed
stand sub assy 3.
2. Remove the lock nut 4, and then remove the screw 1 from the feed stand
sub assy 3.
3
2
1 43
1

Brother LX27NT Specifications

General

Type	Manual sewing machine
Sewing speed	800
Stitch width	5 mm
Feed dog type	5 point
Product color	White
Buttonhole type	1 Step
Number of programs	-
Number of button holes	1
Sewing machine functions	Sewing
Automatic needle threader	Yes
Number of stitch patterns	27
Power supply type	Electric
