3 - 63
Application of Assembly Needle threading mechanism
Application Application
 Type B
1. Set the thread guard cover assy 1 to the thread tension holder assy 2 as
shown in the right figure, and then secure it with the screw 1.
*Key point
• Check that engage the 3 protrusions 3 of the thread tension
holder assy 2 with the 3 gullets of the thread guard cover
assy 1.
<In case of Type A, refer to previous page.>
1
1
13
2
1
Screw, Pan (S/P washer)
M3X6DA

Brother LX27NT Specifications

General

Type	Manual sewing machine
Sewing speed	800
Stitch width	5 mm
Feed dog type	5 point
Product color	White
Buttonhole type	1 Step
Number of programs	-
Number of button holes	1
Sewing machine functions	Sewing
Automatic needle threader	Yes
Number of stitch patterns	27
Power supply type	Electric
