CHAPTER 4 MAINTENANCE AND SERVICING
4-10
(*3) Cushion rubber is used as the member which prevent the fixing roller from hurting when the
copier is transported.
T04-401-03
Unit
Fixing assem-
bly
Maintenance
every every every others
50,000 100,000150,000
×
Remarks
Caution :
Remove the cushion rubber
piece (*3) indicated in the
drowing whenever you are
removing the toner scraping
blade.
F04-401-02
When replacing the lower
fixing roller.
F04-401-03
Part
Toner scraping blade
Oil removing blade
Upper cleaning belt
spring clutch
Upper
web
spring
clutch
Fixing assembly
Toner scraping
blade
Cushion
rubber
