Canon CLC5000 - Page 356

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
CHAPTER 4 MAINTENANCE AND SERVICING
4-11
Unit
Pick-up/feeding
system
Others
Maintenance
every every every others
50,000 100,000150,000
×
Remarks
Every 500,000 copies.
F04-401-04
Collect waste toner
At time of replacing drum/
developer
At time of replacing drum/
developer
At time of replacing drum/
developer
Holding tray
pre-feeding assembly
F04-401-05
Part
Pick-up roller
Feeding roller
Separation roller
Pre-fixing feeding
(top face/belt)
Transfer separation
guide
Registration roller releas-
ing spring clutch
Waste toner box
SALT sensor/shutter*
SALT sensor lower plas-
tic sheet*
Auto gradation correc-
tion
Image position correction
CCD unit (shutter assem-
bly/LED assembly)*
Developing assembly
lower plastic sheet
Pre-holding tray feeding
assembly
Registration roller
replacing spring clutch
Multifeeder assembly
*For details on cleaning, instructions, see CLC1000, Service Manual “Chapter 4 Mechanical System”.
T04-401-04
