CHAPTER 5 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
5-177
Notation Name
COB 1 Terminal base (large)
COB 2 Terminal base (small)
CB 1 Leakage breaker
L 1 Noise filter 1
LF 1 Noise filter 2
F05-601-03
Notation Name
RL 1 Fixing relay
T 1 Deck heater transformer
TR 1 Lower heater triac
TR 2 Upper heater triac
T05-601-03
COB2
L1
TR1
TR2
LF1
COB1
CB1
RL1
T1
