SERVICE MODE
S-43
<DOC-REC (original detection area/slice level)>
<M> <S> <R> <P> <F>
DISP
FUNC
COUNTER
OPTION
TEST
xx
ADJUST
DA-XS
xx
DS-DOC
DA-XE
xx
DS-PRJ
xx
xx
DA-YS
xx
DS-OHP
DA-YE
xx
DOC-REC READY READY
F00-300-05
DAYE
DAYS
DAXEDAXS
DA-XS
*1
DA-XE DA-YS DA-YE
Fine-adjusts the original detection area.
The original must be placed correctly on the copyboard glass in original de-
tection mode; if placed at an angle, the copies will have a black frame. To
prevent the problem, set a value by which such frames will be erased.
F00-300-06
Any changes to the value will affect the frame erasing width in original de-
tection mode when the projector is used.
Settings range –99~99
(0~6.3mm)
Standard: XS=16
XE=16
YS=16
YE=16
Unit=0.06mm (approx.)
