COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON CLC5000 REV.0 JAN. 2001
SERVICE MODE
S-47
<ED/RF (editor/RF adjustment)>
<M> <S> <R> <P> <F>
DISP
FUNC
COUNTER
OPTION
TEST
xxx xxx
xxx mm
ADJUST <TEMP-X>
xxx
xxx mm
<TEMP-Y>
xxx
xxx mm
<ED-X>
xxx
xxx mm
<ED-Y>
ED-MODE
x
EDADJ-X
xxx
LOOP-MB
xxx
LOOP-TH
xxx
EDADJ-Y
ED/RF 1/2 READY READY
F00-300-09
xxx xxx
xxx mm
<TEMP-X>
xxx
xxx mm
<ED-X>
EDADJ-X
Input coordinate adjustment value for sub
scanning direction (X direction) from the Editor
Input coordinate present
values, mm converted
values
Post-correction computed
values, mm converted value
+-
+
-
EDADJ-Y
EDADJ-X
ED-MODE
*1
Switches editor operation mode.
Settings 0: Normal operation
1: 1-point input check
2: Continuous input check
Standard: 0
EDADJ-X
*1
<TEMP-X> <ED-X> EDADJ-Y <TEMP-Y> <ED-Y>
F00-300-10
Settings range –99~+99
(–12.6~+12.6mm)
Unit: 0.13mm (approx.)
Standard: 0
