SERVICE MODE
S-74
F00-300-31
BODY °C
Indicates the machine internal temperature measured by the environment
sensor.
Remarks Same as the reading under ‘DISPLAY > ANALOG’
BODY %
Indicates the machine internal humidity measured by the environment sen-
sor.
Remarks Same as the reading under ‘DISPLAY > ANALOG’
BODY g
Indicates the machine internal humidity absolute value (g) measured by the
environment sensor.
Remarks Same as the reading under ‘DISPLAY > ANALOG’
EL-OFST
Adjusts the transfer high-voltage output.
Settings range –5 ~ +1 (Standard: -2)
Unit: 0.5 kV
ZONE A/B/C
Indicates the machine internal humidity absolute value (g) in the three
ranges of A through C.
Note 1: The setting of this item will return to the default value when the PCB is re-
placed or the RAM is cleared, requiring input once again. Be sure to record
any new setting you have made on the service label.
<HV-EL (fine-adjustment for internal static eliminator high-volt-
age output according to conditions)>
<M> <S> <R> <P> <F>
ADJUST
DISP
FUNC
COUNTER
OPTION
TEST
HV-EL 1/4 READY READY
EL-OFST
xxxx
BODY
BODY
BODY
xxx
xxx
xxx
ZONE A
ZONE B
ZONE C
0.0g
580g
1800g
580g
1800g
-----g
see
see
see
2/4
3/4
4/4
to
to
to
˚C
%
g
