SERVICE MODE
S-111
■ Details of MTR
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Motor
M10 (Multifeeder pickup motor)
*1
M21 (photosensitive drum motor)
*1
M4 (laser scanner motor)
*1
M20 (waste toner feed motor)
*1
M18C, M18M, M18Y, M18Bk (C/M/Y/K
developing motor)
*1
M9 (fixing motor)
*1
M14 (transfer belt motor)
*1
M11 (pre-fixing feed motor)
*1
Buffer pass unit motor
*1
M19 (duplex feed motor)
*1
M15 (polishing/oil removing motor)
*1
M24Y, M24M, M24C, M24Bk (primary
charging wire cleaner motor)
Fixing web motor
Control
Operates for 10 sec, stops for 3 sec, and then
operates for 10 sec and stops.
Operates for 10 sec, stops for 3 sec, and then
operates for 10 sec and stops.
Operates for 10 sec, stops for 3 sec, and then
operates for 10 sec and stops.
Operates for 10 sec, stops for 3 sec, and then
operates for 10 sec and stops.
Operates for 10 sec, stops for 3 sec, and then
operates for 10 sec and stops.
Rotates for 10 sec at standard speed (138
mm/sec) for plain paper (64 to 104 g), for 10
sec at standard speed (90 mm/sec) for thick
paper (157 g), for 10 sec at standard speed
(68 mm/sec) for ultra thick paper (209 g), for
10 sec at gloss speed (45 mm/sec) for ultra
thick paper (209 g), and stops for 3 sec.
Operates for an equivalent of 2 rotations of
the belt and stops for 3 sec; then, operates for
an equivalent of 2 rotations, and stops.
Rotates for 10 sec at standard speed (138
mm/sec) for plain paper (64 to 104 g), for 10
sec at standard speed (90 mm/sec) for thick
paper (157 g), for 10 sec at standard speed
(68 mm/sec) for ultra thick paper (209 g), for
10 sec at gloss speed (45 mm/sec) for ultra
thick paper (209 g), and stops for 3 sec.
Rotates for 10 sec at standard speed (138
mm/sec) for plain paper (64 to 104 g), for 10
sec at standard speed (90 mm/sec) for thick
paper (157 g), for 10 sec at standard speed
(68 mm/sec) for ultra thick paper (209 g), for
10 sec at gloss speed (45 mm/sec) for ultra
thick paper (209 g), and stops for 3 sec.
Operates for 10 sec, stops for 3 sec, and then
operates for 10 sec and stops.
Rotates CCW/CW for 10 sec, stops for 3 sec,
rotates CCW for 10, and then stops.
Cleans by a single back-and-forth trip.
Operates for 5 sec and then stops.
Note 1: Its operation stops in response to a press on the Stop key.
