SERVICE MODE
S-110
No.
5
6
7
8
9
High-voltage output
Primary Y/M/C/K primary charging assembly,
C/M/Y/K grid output, C/M/Y/K transfer
high-voltage, developing bias C/M/Y/K-DC
(–370 V) output, internal static eliminator as-
sembly, separation charging assembly output
Developing bias C-AC/DC output, anti-stray
toner high-voltage output
Developing bias M-AC/DC output, anti-stray
toner high-voltage output
Developing bias Y-AC/DC output, anti-stray
toner high-voltage output
Developing bias K-AC/DC output, anti-stray
toner high-voltage output
Control
Transfer lifter UP, photosensitive drum motor
ON, pre-exposure ON, belt motor ON, trans-
fer blade ON
C/M/Y/K primary output, grid output (500
V), developing bias DC (-370 V) output, in-
ternal static eliminator assembly output, sepa-
ration charging output, transfer charging out-
put ON
(Waits for a stop command while the transfer
belt makes 10 rotations.)
Transfer charging output, internal static elimi-
nator assembly output, separation charging
output OFF, transfer blade OFF, post rotation
sequence
Developing bias C-AC/DC output, anti-stray
toner high-voltage output ON
(Waits for a stop command, or 60 sec.)
Developing bias C-AC/DC output, anti-stray
toner high-voltage output OFF
Developing bias M-AC/DC output, anti-stray
toner high-voltage output ON
(Waits for a stop command, or 60 sec.)
Developing bias M-AC/DC output, anti-stray
toner high-voltage output OFF
Developing bias Y-AC/DC output, anti-stray
toner high-voltage output ON
(Waits for a stop command, or 60 sec.)
Developing bias Y-AC/DC output, anti-stray
toner high-voltage output OFF
Developing bias K-AC/DC output, anti-stray
toner high-voltage output ON
(Waits for a stop command, or 60 sec.)
Developing bias K-AC/DC output, anti-stray
toner high-voltage output OFF
