SERVICE MODE
S-117
Feeding
direction
Rear
Front
<IMG-REG (image position correction control)>
<M> <S> <R> <P> <F>
DISP
AUTO-ADJ
ADJUST
COUNTER
M-READ
M-WR-F
M-WR-R
FUNC
OPTION
TEST
0
XXX
XXX
C-REG-H
XXX
Y-REG-H
XXX
K-REG-H
XXX
X
C-REG-HS
X
Y-REG-HS
X
K-REG-HS
XXX
XXX
C-REG-V
XXX
Y-REG-V
XXX
K-REG-V
IMG-REG READY
1/2
F00-400-26
AUTO-ADJ
Use it to execute the series of operations for image position correction con-
trol.
<P>READY→SERVICE→READY
Remarks 1 min (approx.)
M-READ
Use it to indicate the start position of reading the pattern for M.
M-W-F
M-W-R
Use it to indicate the start position of writing the pattern for M.
F: Front.
R: Rear.
Y/C/K-REG-H
Use it to correct the write start position of the pattern for Y/C/K. (rough ad-
justment in main scanning direction)
Do not use this item unless ‘E194’ is indicated (error that dis-
ables image position correction)
Remarks A higher setting shifts the pattern to the rear.
F00-400-27
Settings range 0 ~ 255
Standard: 128
Unit: 1 pixel (63.5µm)
