SERVICE MODE
S-118
Y/C/K-REG-HS
Use it to correct the write start position of the pattern for Y/C/K. (fine
adjusment in main scanning divection)
Do not use this item unless ‘E194’ is indicated (error that dis-
ables image position correction).
Settings range
0 ~ 3
Standard: 0
Unit: 1/4 pixel
Y/C/K-REG-V
Use it to correct the write start position of the pattern for Y/C/K. (fine ad-
justment in main scanning direction)
Use it to correct the write start position of the pattern for Y/C/K. (sub scan-
ning direction)
Do not use this item unless ‘E194’ is indicated (error that dis-
ables image position correction).
Remarks A higher setting will shift the pattern to the trailing edge.
F00-400-28
Settings range
0 ~ 255
Standard: 128
Unit: 1 pixel (63.5µm)
Leading
edge
Feeding
direction
Trailing
edge
