SERVICE MODE
S-119
REG-ERR-FLG
Indicates how the image position correction pattern is read.
0:0000 through 7:0000 corresponds to 8 sets of patterns.
(‘0000’ indicates the absence of an error; if an error is found in all 8 sets, ‘E194’ will be
indicated. If any of the sets is ‘0000’, its data will be used for correction.)
0 : 0 1 6 A
set 1 through set 8
Y pattern
M pattern
C pattern
Bk pattern
4-bit data is assigned to each color data, and a ‘1’ is assigned where an error exists.
0 : 0 1 6 A
0 1 1 0
front main scanning
front sub scanning
rear main scanning
rear sub scanning
In the case of the above, an error exists on the pattern for C of set 1 at front in sub scan-
ning direction and at rear in main scanning direction.
F00-400-29
<M> <R> <P> <F>
DISP
ADJUST
COUNTER
FUNC
OPTION
TEST
IMG-REG READY
<S>
REG-ERR-FLG
4: 0000
0: 0000
5: 0000
1: 0000
6: 0000
2: 0000
7: 0000
3: 0000
2/2
