2. Put the Long Lifter Wire through the Pulley [1] and then fix it.
• 1 Screw [2]
NOTE:
Put the Lifter Wire between the roller and the fixing plate from the left side as shown in the figure.
Long Lifter Wire
Roller
Fixing Plate
RightLeft
[2]
[1]
1x
4. Parts Replacement and Cleaning
154
