NOTE:
Air assist control is performed in the same manner for all decks.
Pickup direction
Warm air Cool air
Pickup Roller
Pickup/Feed Roller
Separation Roller
Flotation Fan 1
（FAN101/ FAN201/ FAN301）
Flotation Fan 2
（FAN102/ FAN202/ FAN302）
Air Heater Unit
（AHT101/ AHT201/ AHT301）
Paper
● FAN, Swing, Air heater Control
Paper Type
Ultra Small size Small size Large size
Air Heater
Unit
AHT101
AHT201
AHT301
Swing
Motor
M102
M202
M302
Flotation
Fan 1
FAN101
FAN201
FAN301
(Warming)
Flotation
Fan 2
FAN102
FAN202
FAN302
(Cooling)
Flotation
Fan 1
FAN101
FAN201
FAN301
(Warming)
Flotation
Fan 2
FAN102
FAN202
FAN302
(Cooling)
Flotation
Fan 1
FAN101
FAN201
FAN301
(Warming)
Flotation
Fan 2
FAN102
FAN202
FAN302
(Cooling)
Non
coated
paper
Thin paper (52 to
63 g/m
2
), Plain pa-
per (64 to 105 g/
m
2
), Heavy paper
(106 to 150 g/m
2
),
Bond paper
OFF OFF OFF OFF OFF OFF OFF OFF
Heavy paper(151
to 400 g/m
2
), Recy-
cled paper
ON OFF ON ON ON ON OFF ON
Coated paper ON OFF ON ON ON ON ON ON
Spe-
cial pa-
per
Transparency/Film ON OFF ON ON ON ON OFF ON
Textured paper ON OFF ON ON ON ON OFF ON
Label ON OFF ON ON ON ON OFF ON
Postcard OFF OFF OFF OFF OFF OFF OFF ON
Envelope OFF OFF OFF OFF OFF OFF OFF OFF
Synthetic ON OFF ON ON ON ON ON ON
