• Paper size is described for detail as follows.
Ultra small: 228.6 mm or less paper length
Small: 228.7 to 297 mm paper length
Large: 297.1 to 488 mm paper length
• Switches the ON/OFF and wind-power of fan according to the detected temperature and humidity of the Environment Sensor
(S007).
• Switches the ON/OFF and temperature setting of heater according to the detected temperature and humidity of the
Environment Sensor (S007).
NOTE:
Service Mode
• To adjust the airflow amount of the Air Floatation Fan (Upstream) of the Multi Deck (Upper).
COPIER> OPTION> FEED-SW> MD-ALVU1
• To adjust the airflow amount of the Air Floatation Fan (Downstream) of the Multi Deck (Upper).
COPIER> OPTION> FEED-SW> MD-ALVD1
To adjust the airflow amount of the Air Floatation Fan of the Multi-drawer Paper Deck.
When making an adjustment, be sure to adjust the setting of MD-ALVD1 and MD- ALVU1 at the same time.
Middle deck and Lower deck uses the following service modes.
(MD-ALVU2, MD-ALVD2, MD-ALVU3, MD-ALVD3)
• To adjust the airflow amount of the Air Floatation Fan (Upstream) of the Secondary Multi Deck (Upper).
COPIER> OPTION> FEED-SW> MD2ALVU1
• To adjust the airflow amount of the Air Floatation Fan (Downstream) of the Secondary Multi Deck (Upper).
COPIER> OPTION> FEED-SW> MD2ALVD1
To adjust the airflow amount of the Air Floatation Fan of the Multi-drawer Paper Deck.
When making an adjustment, be sure to adjust the setting of MD2ALVD1 and MD2ALVU1 at the same time.
Middle deck and Lower deck uses the following service modes.
(MD2ALVU2, MD2ALVD2, MD2ALVU3, MD2ALVD3)
User Mode
• [Settings/Registration]> [Preferences]> [Paper Settings]> [Paper Type Management Settings]> [Adj. Ppr Separation Fan
Level]
<Use case>
• When double-feed occurs.
■ Swing Operation
This equipment combines the air blowing operation against paper with the swing operation of the shutter to improve separation
of paper.
The Swing Motor (M102/M202/M302) drives the shutter to move up and down. The direction of air blow against paper changes
up or down repeatedly, vibrating the paper for easier separation.
The Swing HP Sensor (S114/S215/S315) detects a failure of up and down operation of the shutter and the home position of the
shutter.
NOTE:
Swing operation is performed in the same manner for all decks.
2. Technology
25
