Capintec CRC-25R - Page 176

CAPINTEC, INC. CRC
®
-25R
d. Gently press the battery in the direction of the arrow (toward the end of the
battery holder with the three prongs) as shown in Figure 15-5.
Figure 15-5
e. Lift the other end of the battery up and slide it out. The battery holder will
appear as shown in Figure 15-6.
Figure 15-6
15 - 8 CLEANING AND MAINTENANCE March 15
