3. Battery Installation
a. Locate the new battery and verify the proper orientation as shown in Figure
15-7 – the positive (+) side of the battery must face up.
Figure 15-7
b. Slide the battery into the battery holder under the three prongs as shown in
Figure 15-8.
Figure 15-8
