6.
CHECK SECONDARY IGNITION SYSTEM
• Perform the following to test the secondary ignition system:
− Disconnect the injector fuse.
− Remove any of the 4 spark plugs.
− Connect the spark plug to spark plug wire.
− Ground the spark plug on the cylinder block.
− Crank the engine to test the secondary ignition system with the spark plugs removed.
Is a strong blue spark visible at each spark plug while cranking the engine?
Yes
>> Go to the next step.
No
>>
Check Camshaft Position (CMP) sensor signal at ECM.
If CMP sensor is OK, check the following:
− Crankshaft Position (CKP) sensor malfunction
− Spark plug wires
− Spark plugs
7.
CHECK FUEL SYSTEM PRESSURE
• Release the fuel system pressure (See Fuel Pressure Relief Procedure in Section 04 Fuel Delivery).
• Check fuel system pressure (See Fuel Pressure Test in Section 04 Fuel Delivery).
Is fuel pressure correct?
Yes
>> Go to the next step.
No
>>
If the fuel pressure is greater than 400 kPa (4 bar):
− Replace the fuel pressure regulator.
If the fuel pressure is less than 400 kPa (4 bar):
− Check fuel supply system for restriction or leak.
− If no problems, repair or replace fuel filter, pressure regulator or fuel pump assembly.
8.
CHECK EXHAUST SYSTEM
• Check the exhaust system for restrictions.
Is there a restriction in the exhaust system?
Yes
>> Repair as necessary.
No
>> Go to the next step.
9.
CHECK PCV SYSTEM
• Check the Positive Crankcase Ventilation (PCV) system.
• Remove PCV valve and shake it.
Is PCV valve normal?
Yes
>> Go to the next step.
No
>> Replace the PCV valve.
ELECTRONIC ENGINE CONTROLS - ENGINE SYMPTOM DIAGNOSIS
03
03–195
Chery Automobile Co., Ltd.
