On Board Diagnostic Logic
Self-diagnosis detection logic.
DTC NO. DTC DEFINITION
DTC DETECTION
CONDITION
DTC SET
CONDITION
POSSIBLE CAUSES
P0914 Shift position sensor Engine is running
The Automated
Manual Transaxle
(AMT) control
module detects that
the voltage is out of
the acceptable
range.
If this DTC is set,
the AMT can only be
shifted up to 3rd
gear forcibly.
Gear position
sensor
Harness or
connectors (The
sensor circuit is open
or shorted)
AMT control
module
AMT electro-
mechanical control
unit
DTC Confirmation Procedure:
Before performing the following procedure, confirm that battery voltage is more than 12 V.
Turn ignition switch off.
Connect the X-431 scan tool to the Data Link Connector (DLC) - use the most current software available.
Turn ignition switch on, with the scan tool, view and erase stored DTCs in the Automated Manual Transaxle
(AMT) control module.
Start the engine and warm it to normal operating temperature.
Drive the vehicle and attempt to operate the gear selection lever to every gear condition required for this test.
With the scan tool, select view DTC and data stream.
If the DTC is detected, the DTC condition is current. Go to Diagnostic Procedure - Step 1.
If the DTC is not detected, the DTC condition is intermittent (See Diagnostic Help and Intermittent DTC Trou-
bleshooting in Section 08 Transaxle for more information).
NOTE :
Using the appropriate diagnostic test tool, you can diagnose the AMT control module harness while the AMT con-
trol module is still connected. This will help prevent electrical connector terminal damage.
