Diagnostic Procedure
1.
CHECK HYDRAULIC PRESSURE SENSOR SIGNAL
• With the scan tool, select view DTC and data
stream for AMT.
• Start vehicle and monitor the value of 9HYDRAULIC
PRESSURE9.
ITEM CONDITION DISPLAY VALUE
System Pressure Idle or driving 40 - 52 bar
Is the check result normal?
Yes
>> The conditions that caused this DTC to set are not present at this time (See Diagnostic Help in Section
08 Transaxle).
No
>> Go to the next step.
2.
CHECK HYDRAULIC PRESSURE SENSOR ELECTRICAL CONNECTOR
• Stop the vehicle and turn ignition switch off.
• Disconnect the hydraulic pressure sensor electrical
connector P-009.
• Inspect the electrical connector for damage.
Is the electrical connector OK?
Yes
>> Go to the next step.
No
>> Repair or replace the electrical connector
as necessary.
DIAGNOSIS & TESTING
PZSMD080031T
PZSMD080001
08
08–93
Chery Automobile Co., Ltd.
