Diagnostic Procedure
1.
CHECK CLUTCH SOLENOID SIGNAL
• With the scan tool, select view DTC and data
stream for AMT.
• Start the engine.
• Monitor the value of the clutch solenoid as indi-
cated in the following table while driving:
X-431 Reference Value
ITEM CONDITION CURRENT VALUE
Clutch Vehicle is driving OK
Is the check result normal?
Yes
>> The conditions that caused this DTC to set are not present at this time (See Diagnostic Help in Section
08 Transaxle).
No
>> Go to the next step.
2.
ACTUATE TEST
• With the X-431, perform the solenoid actuate test.
• The solenoid should be heard.
Is the check result normal?
Yes
>> Go to step 8.
No
>> Go to the next step.
DIAGNOSIS & TESTING
PZSMD080031T
08–98
Chery Automobile Co., Ltd.
