ON-VEHICLE SERVICE
Front Hub and Bearing
Removal & Installation
1. Raise and support the vehicle.
2. Remove the wheel mounting nuts and the tire and wheel assembly.
(Tighten: Wheel mounting nuts to 110 N·m)
3. Remove the front axle hub nut from the front
knuckle.
(Tighten: Front axle hub nut to 135 N·m)
4. Remove the front brake rotor (See Brake Rotor Removal & Installation in Section 12 Brakes).
5. Using a bearing puller, remove the hub (1) and
bearing from the front knuckle.
6. Installation is in the reverse order of the removal.
BESM100001
PZSM090001
09
09–5
