9. Remove the lower ball joint mounting nut (1)
attaching the lower control arm to the knuckle.
(Tighten: Steering knuckle pinch bolt to 110 ± 10
N·m)
10. Using special tool CH-10002, separate the ball joint
from the steering knuckle.
11. While holding the bolt heads stationary, remove the
two nuts (1) from the bolts attaching the strut
assembly to the steering knuckle.
(Tighten: Strut to steering knuckle bolts to 110 ± 10
N·m)
ON-VEHICLE SERVICE
PZSM100013
LTSM110027
PZSM100025
10–8
Chery Automobile Co., Ltd.
