Front Strut Rod
Removal & Installation
1. Raise and support the vehicle.
2. Remove the wheel mounting nuts and the wheel assembly.
(Tighten: Wheel mounting nuts to 110 N·m)
3. Remove the two strut rod bolts (1) attaching the
strut rod to lower control arm.
(Tighten: Strut rod bolts to 75 ± 5 N·m)
4. Remove the strut rod nut (1) attaching the strut rod
to sub-frame.
(Tighten: Strut rod nut to 105 ± 5 N·m)
5. Remove the strut rod.
6. Installation is in the reverse order of removal.
ON-VEHICLE SERVICE
PZSM100016
PZSM100024
10
10–13
Chery Automobile Co., Ltd.
