4. Remove the bolts (1) securing the stabilizer bar
bushing retainers to the sub-frame.
(Tighten: Stabilizer bar bushing retainer bolts to 50
± 5 N·m)
5. Remove the two stabilizer bar bushing retainers.
6. Remove the stabilizer bar from the vehicle.
7. Installation is in the reverse order of removal.
Front Stabilizer Bar Link
Removal & Installation
1. Raise and support the vehicle.
2. Remove the wheel mounting nuts and the wheel assembly.
(Tighten: Wheel mounting nuts to 110 N·m)
3. Remove the stabilizer bar link nuts (1) attaching
the stabilizer bar to stabilizer bar link.
(Tighten: Stabilizer bar link nuts to 110 ± 10 N·m)
4. Remove the lower control arm to the stabilizer bar
link nut (1).
(Tighten: Lower control arm to the stabilizer bar link
nut to 110 ± 10 N·m)
5. Installation is in the reverse order of removal.
Installation Notes:
• After installation, each bolt must be tightened to the required tightening torque.
ON-VEHICLE SERVICE
PZSM100009
PZSM100012
PZSM100026
10–12
Chery Automobile Co., Ltd.
