î˜ Drill a hole to discharge the gas in the strut assembly cylinder (Drill a hole in the cylinder body according to
the figure to discharge the gas).
Assembly
1. Replace all necessary parts prior to reassembly:
1. Cushion Pad
2. Dust Boot
3. Cushion Block
4. Upper Spring Seat
5. Upper Spring Mount
2. Mount the new strut assembly into the fixture.
3. Insert the coil spring into the spring compressor.
4. Compress the coil spring to a distance of î˜ 120 mm
between the two clamps.
UNIT REPAIR
LTSM100012
LTSM100016
LTSM100017
LTSM100018
10
10–25
Chery Automobile Co., Ltd.
