ANTILOCK BRAKES
GENERAL INFORMATION
12-26
Description 12-26
Operation 12-26
Specifications 12-27
Special Tools 12-27
Electrical Schematics 12-28
Antilock Brake System (ABS) Module
Connector Pin-Out Table 12-31
DIAGNOSIS & TESTING
12-32
Diagnostic Help 12-32
Intermittent DTC Troubleshooting 12-32
Ground Inspection 12-32
Diagnostic Tools 12-32
Diagnostic Trouble Code (DTC) List 12-33
Antilock Brake System DTC List 12-33
Diagnostic Trouble Code (DTC) Tests 12-34
C1101 - Battery Voltage High, C1102 -
Battery Voltage Low 12-34
C1200 - Left Front Wheel Speed
Sensor Circuit Open or Shorted 12-39
C1202 - Left Front Wheel Speed
Sensor Gap Error 12-43
C1203 - Right Front Wheel Speed
Sensor Circuit Open or Shorted 12-47
C1205 - Right Front Wheel Speed
Sensor Gap Error 12-51
C1206 - Left Rear Wheel Speed Sensor
Circuit Open or Shorted 12-55
C1208 - Left Rear Wheel Speed Sensor
Gap Error 12-60
C1209 - Right Rear Wheel Speed
Sensor Circuit Open or Shorted 12-64
C1211 - Right Rear Wheel Speed
Sensor Gap Error 12-69
C1604 - ECU Defect, Internal Errors or
Solenoid Fault 12-73
ON-VEHICLE SERVICE
12-75
Antilock Brake System (ABS) Bleeding
Procedure 12-75
ABS Bleeding Information 12-75
ABS Bleeding Instructions 12-75
Manual Bleeding Instructions 12-76
Pressure Bleeding Instructions 12-76
Antilock Brake System (ABS) Hydraulic
Control Module 12-77
Removal & Installation 12-77
Front Wheel Speed Sensor 12-77
Removal & Installation 12-77
Rear Wheel Speed Sensor 12-78
Removal & Installation 12-78
12
12–25
Chery Automobile Co., Ltd.
