Chery A1 2009 User Manual

RESTRAINTS
14
CONTENTS
page
Airbag System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-1
Seat Belt System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-39
AIRBAG SYSTEM
GENERAL INFORMATION
14-2
Description 14-2
Operation 14-2
Specifications 14-2
Special Tools 14-3
Electrical Schematics 14-4
Restraints Control Module (RCM)
Connector Pin-Out Table 14-7
DIAGNOSIS & TESTING
14-8
Diagnostic Help 14-8
Intermittent DTC Troubleshooting 14-8
Ground Inspection 14-8
Diagnostic Tools 14-8
Diagnostic Trouble Code (DTC) List 14-9
Restraints Control Module DTC List 14-9
Diagnostic Trouble Code (DTC) Tests 14-11
B1200 - ECU Internal Errors 14-11
B1400 - Power Supply Under Volt 14-16
B1241 - Front Driver Airbag I °STAGE
Open Circuit or Over Upper Limit or
Vbatt Voltage Lost 14-21
B1245 - Front Passenger Airbag I
°STAGE Open Circuit or Over Upper
Limit or Vbatt Voltage Lost 14-27
B2214 - Warning Lamp Short to Ground 14-32
ON-VEHICLE SERVICE
14-36
Airbag System Disarming Procedure 14-36
Description 14-36
Driver Airbag 14-36
Removal & Installation 14-36
Front Passenger Airbag 14-37
Removal & Installation 14-37
Restraints Control Module (RCM) 14-38
Removal & Installation 14-38
14
14–1
Chery Automobile Co., Ltd.
