Cisco Catalyst 3750-X Command Reference

2-68
Catalyst 3750-X and 3560-X Switch Command Reference
OL-29704-01
Chapter 2 Catalyst 3750-X and 3560-X Switch Cisco IOS Commands
auto qos voip
Switch(config-pmap-c)# police 5000000 8000 exceed-action drop
Switch(config-pmap)# class AUTOQOS_BULK_DATA_CLASS
Switch(config-pmap-c)# set dscp af11
Switch(config-pmap-c)# police 10000000 8000 exceed-action policed-dscp-transmit
Switch(config-pmap)# class AUTOQOS_TRANSACTION_CLASS
Switch(config-pmap-c)# set dscp af21
Switch(config-pmap-c)# police 10000000 8000 exceed-action policed-dscp-transmit
Switch(config-pmap)# class AUTOQOS_SCAVANGER_CLASS
Switch(config-pmap-c)# set dscp cs1
Switch(config-pmap-c)# police 10000000 8000 exceed-action drop
Switch(config-pmap)# class AUTOQOS_SIGNALING_CLASS
Switch(config-pmap-c)# set dscp cs3
Switch(config-pmap-c)# police 32000 8000 exceed-action drop
Switch(config-pmap)# class AUTOQOS_DEFAULT_CLASS
Switch(config-pmap-c)# set dscp default
Switch(config-if)# service-policy input AUTOQOS-SRND4-SOFTPHONE-POLICY
Examples This example shows how to enable auto-QoS and to trust the QoS labels received in incoming packets
when the switch or router connected to the port is a trusted device:
Switch(config)# interface gigabitethernet2/0/1
Switch(config-if)# auto qos voip trust
You can verify your settings by entering the show auto qos interface interface-id privileged EXEC
command.
Related Commands Command Description
debug auto qos Enables debugging of the auto-QoS feature.
mls qos cos Defines the default CoS value of a port or assigns the default
CoS to all incoming packets on the port.
mls qos map cos-dscp Defines the CoS-to-DSCP map or the DSCP-to-CoS map.
mls qos queue-set output buffers Allocates buffers to a queue-set.
mls qos srr-queue input bandwidth Assigns shaped round robin (SRR) weights to an ingress
queue.
mls qos srr-queue input buffers Allocates the buffers between the ingress queues.
mls qos srr-queue input cos-map Maps CoS values to an ingress queue or maps CoS values to
a queue and to a threshold ID.
mls qos srr-queue input dscp-map Maps DSCP values to an ingress queue or maps DSCP values
to a queue and to a threshold ID.
mls qos srr-queue input
priority-queue
Configures the ingress priority queue and guarantees
bandwidth.
mls qos srr-queue output cos-map Maps CoS values to an egress queue or maps CoS values to
a queue and to a threshold ID.
mls qos srr-queue output dscp-map Maps DSCP values to an egress queue or maps DSCP values
to a queue and to a threshold ID.
mls qos trust Configures the port trust state.
queue-set Maps a port to a queue-set.
show auto qos Displays auto-QoS information.
show mls qos interface Displays QoS information at the port level.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
