Cisco Catalyst 3750-X Command Reference

2-834
Catalyst 3750-X and 3560-X Switch Command Reference
OL-29704-01
Chapter 2 Catalyst 3750-X and 3560-X Switch Cisco IOS Commands
show vtp
This is an example of output from the show vtp status command. Table 2-55 describes each field in the
display.
Switch> show vtp status
VTP Version : 2
Configuration Revision : 0
Maximum VLANs supported locally : 1005
Number of existing VLANs : 45
VTP Operating Mode : Transparent
VTP Domain Name : shared_testbed1
VTP Pruning Mode : Disabled
VTP V2 Mode : Disabled
VTP Traps Generation : Enabled
MD5 digest : 0x3A 0x29 0x86 0x39 0xB4 0x5D 0x58 0xD7
Number of configuration
revision errors
Number of revision errors.
Whenever you define a new VLAN, delete an existing one, suspend or resume an existing
VLAN, or modify the parameters on an existing VLAN, the configuration revision number
of the switch increments.
Revision errors increment whenever the switch receives an advertisement whose revision
number matches the revision number of the switch, but the MD5 digest values do not match.
This error means that the VTP password in the two switches is different or that the switches
have different configurations.
These errors means that the switch is filtering incoming advertisements, which causes the
VTP database to become unsynchronized across the network.
Number of configuration digest
errors
Number of MD5 digest errors.
Digest errors increment whenever the MD5 digest in the summary packet and the MD5
digest of the received advertisement calculated by the switch do not match. This error
usually means that the VTP password in the two switches is different. To solve this problem,
make sure the VTP password on all switches is the same.
These errors mean that the switch is filtering incoming advertisements, which causes the
VTP database to become unsynchronized across the network.
Number of V1 summary errors Number of Version 1 errors.
Version 1 summary errors increment whenever a switch in VTP V2 mode receives a VTP
Version 1 frame. These errors mean that at least one neighboring switch is either running
VTP Version 1 or VTP Version 2 with V2-mode disabled. To solve this problem, change the
configuration of the switches in VTP V2-mode to disabled.
Join Transmitted Number of VTP pruning messages sent on the trunk.
Join Received Number of VTP pruning messages received on the trunk.
Summary Advts Received from
non-pruning-capable device
Number of VTP summary messages received on the trunk from devices that do not support
pruning.
Table 2-54 show vtp counters Field Descriptions (continued)
Field Description

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
