52-52
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 52 Configuring QoS
Configuring QoS on the Switch
To create or modify a named IPX ACL, perform this task in privileged mode:
The protocol parameter can be specified numerically (0–255) or with these keywords: any, ncp (17),
netbios (20), rip (1), sap (4), or spx (5).
The src_net and dest_net parameters are IPX network numbers, entered as up to 8 hexadecimal digits in
the range 1 to FFFFFFFE (-1 matches any network number). You do not need to enter leading zeros.
If you specify an IPX destination network, the IPX ACEs support the following optional parameters:
• An IPX destination network mask, entered as up to 8 hexadecimal digits in the range 1 to FFFFFFFE
(-1 matches any network number). Use one bits, which need not be contiguous, where you want the
wildcards.
• An IPX destination node, entered as 12 hexadecimal digits (48 bits), formatted as a dotted triplet of
four-digit hexadecimal digits each (xxxx.xxxx.xxxx).
• If you specify an IPX destination node, the IPX ACEs support an IPX destination node mask,
entered as 12 hexadecimal digits (48 bits), formatted as a dotted triplet of four-digit hexadecimal
digits each (xxxx.xxxx.xxxx). Use one bits, which need not be contiguous, where you want the
wildcards.
This example shows how to create an IPX ACE:
Console> (enable) set qos acl ipx my_IPXacl trust-cos aggregate my-agg -1
my_IPXacl editbuffer modified. Use ‘commit’ command to apply changes.
Console> (enable)
Task Command
Step 1
Create or modify a named IPX ACL. With a PFC:
set qos acl ipx acl_name {dscp dscp_value |
trust-cos} [aggregate aggregate_name] protocol
src_net [dest_net[.dest_node][[dest_net_mask]
.dest_node_mask]] [before editbuffer_index |
modify editbuffer_index]
With PFC2:
set qos acl ipx acl_name aggregate
aggregate_name protocol src_net
[dest_net[.dest_node][[dest_net_mask]
.dest_node_mask]] [before editbuffer_index |
modify editbuffer_index]
Step 2
Verify the configuration. show qos acl info {acl_name | all}
editbuffer [editbuffer_index]
