Page #74 background imageLoading...
Page #74 background image
4-4
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 4 Configuring Ethernet, Fast Ethernet, Gigabit Ethernet, and 10-Gigabit Ethernet Switching
Setting the Port Configuration
Setting the Port Configuration
These sections describe how to configure Ethernet, Fast Ethernet, Gigabit Ethernet, and 10-Gigabit
Ethernet switching on the Catalyst 6500 series switches:
Configuring Supervisor Engine 720 Ports, page 4-5
Setting the Port Name, page 4-5
Setting the Port Speed, page 4-6
Setting the Port Duplex Mode, page 4-6
Enabling or Disabling Auto-MDI/MDIX, page 4-7
Configuring IEEE 802.3x Flow Control, page 4-8
Enabling and Disabling Port Negotiation, page 4-9
Changing the Default Port Enable State, page 4-9
Setting the Port Debounce Timer, page 4-10
Modifying the Port Debounce Timer Setting, page 4-11
Duplex mode
Half duplex for 10-Mbps Ethernet ports
Autonegotiate speed and duplex for 10/100-Mbps Fast Ethernet
ports
Autonegotiate duplex for 100-Mbps Fast Ethernet ports
Full duplex for 1000-Mbps Gigabit Ethernet ports
Full duplex for 10000-Mbps Gigabit Ethernet ports
Flow control (10-Gigabit
Ethernet)
Flow control set to on for receive (Rx) and off for transmit (Tx)
1
Flow control (Gigabit Ethernet) Flow control set to off for receive (Rx) and desired for transmit (Tx)
Flow control (other Ethernet) Flow control set to off for receive (Rx); transmit (Tx) not supported
Spanning Tree Protocol (STP) Enabled for VLAN 1
Native VLAN VLAN 1
Port VLAN cost
100 for 10-Mbps Ethernet ports
19 for 10/100-Mbps Fast Ethernet ports
19 for 100-Mbps Fast Ethernet ports
4 for 1000-Mbps Gigabit Ethernet ports
1 for 10000-Mbps Gigabit Ethernet ports
EtherChannel Disabled on all Ethernet ports
Jumbo frames Disabled on all Ethernet ports
1. On WS-X6502-10-Gigabit Ethernet ports, flow control on the receive side is always on and cannot be set to off. On
WS-X6704, WS-X6708-10-Gigabit Ethernet ports and Supervisor Engine 720-10 Gigabit Ethernet uplink ports flowcontrol
for both send and receive side can be set to off.
Table 4-2 Ethernet Default Configuration (continued)
Feature Default Value
