19-9
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 19 Configuring Dynamic Port VLAN Membership with VMPS
Troubleshooting VMPS and Dynamic Port VLAN Membership
VMPS Client Status:
---------------------
VMPS VQP Version: 1
Reconfirm Interval: 60 min
Server Retry Count: 3
VMPS domain server:
No dynamic ports configured.
Console>
Troubleshooting VMPS and Dynamic Port VLAN Membership
These sections describe how to troubleshoot VMPS and dynamic port VLAN membership:
• Troubleshooting VMPS, page 19-9
• Troubleshooting Dynamic Port VLAN Membership, page 19-10
Troubleshooting VMPS
Table 19-2 shows the VMPS error messages that you might see when you enter the set vmps state
enable or the download vmps command.
After VMPS successfully downloads the VMPS database configuration file, it parses the file and builds
a database. When the parsing is complete, VMPS outputs statistics about the total number of lines that
are parsed and the number of parsing errors.
To obtain more information on the VMPS parsing errors, set the syslog level for VMPS to 3 using the
set logging level vmps 3 command.
Table 19-2 VMPS Error Messages
VMPS Error Message Recommended Action
TFTP server IP address is not configured.
Specify the TFTP server address using the set vmps tftpserver
ip_addr [filename] command.
Unable to contact the TFTP server
172.16.254.222.
Enter a static route (using the set ip route command) to the
TFTP server.
File “vmps_configuration.db” not found on the
TFTP server 172.16.254.222.
Check the filename of the VMPS database configuration file on
the TFTP server. Make sure that the permissions are set
correctly.
Enable failed due to insufficient resources.
The switch does not have sufficient resources to run the
database. You can fix this problem by increasing the dynamic
random-access memory (DRAM).
