7-50
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 7 Configuring Spanning Tree
Configuring Spanning-Tree Timers on the Switch
Configuring the Hello Time
Enter the set spantree hello command to change the hello time for a VLAN, an MISTP instance, or on
a per-port basis. The possible range of interval is 1–10 seconds.
To configure the spanning-tree bridge hello time for a VLAN or an MISTP instance, perform this task
in privileged mode:
This example shows how to configure the spanning-tree hello time for VLAN 100 to 7 seconds:
Console> (enable) set spantree hello 7 100
Spantree 100 hello time set to 7 seconds.
Console> (enable)
This example shows how to configure the spanning-tree hello time for an instance to 3 seconds:
Console> (enable) set spantree hello 3 mistp-instance 1
Spantree 1 hello time set to 3 seconds.
Console> (enable)
This example shows how to configure the spanning-tree hello time for port 4/5 to 4 seconds:
Console> (enable) set spantree hello 4 mst 4/1
MST hello time set to 4 on port 4/1.
Console> (enable)
Configuring the Forward Delay Time
Enter the set spantree fwddelay command to configure the spanning-tree forward delay time for a
VLAN. The possible range of delay is 4–30 seconds.
To configure the spanning-tree forward delay time for a VLAN, perform this task in privileged mode:
This example shows how to configure the spanning-tree forward delay time for VLAN 100 to
21 seconds:
Console> (enable) set spantree fwddelay 21 100
Spantree 100 forward delay set to 21 seconds.
Console> (enable)
This example shows how to set the bridge forward delay for an instance to 16 seconds:
Task Command
Step 1
Configure the hello time for a VLAN or an
MISTP instance.
set spantree hello interval {[vlan] | mistp-instance
[instances] | mst [mod/port]}
Step 2
Verify the configuration. show spantree [vlan | mistp-instance instances]
Task Command
Step 1
Configure the forward delay time for a VLAN or
an MISTP instance.
set spantree fwddelay delay [vlan]
mistp-instance [instances]
Step 2
Verify the configuration. show spantree [mod/port] mistp-instance
[instances] [active]
