22-16
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 22 Administering the Switch
Displaying System Status Information for Technical Support
Displaying System Status Information for Technical Support
These sections describe how to display the system status information for technical support:
• Generating a System Status Report, page 22-17
• Using System Dump Files, page 22-17
• Using System Crash-Info Files, page 22-19
Table 22-2 Environmental Monitoring for Supervisor Engine and Switching Modules
Component
Alarm
Type LED Indication Action
Supervisor engine
temperature sensor exceeds
major threshold
1
1. The temperature sensors monitor the key supervisor engine components including the daughter cards.
Major STATUS
2
LED red
3
2. A STATUS LED is located on the supervisor engine front panel and all the module front panels.
3. The STATUS LED is red on the failed supervisor engine. If there is no redundant supervisor engine, the SYSTEM LED is
red also.
syslog message and SNMP trap
generated.
If redundancy, system switches to the
redundant supervisor engine and the
active supervisor engine shuts down.
If there is no redundancy and the
overtemperature condition is not
corrected, the system shuts down after
5minutes.
Supervisor engine
temperature sensor exceeds
minor threshold
Minor STATUS LED
orange
syslog message and SNMP trap
generated.
Monitor the condition.
Redundant supervisor engine
temperature sensor exceeds
major or minor threshold
Major STATUS LED red syslog message and SNMP trap
generated.
If major alarm and the overtemperature
condition is not corrected, the system
shuts down after 5 minutes.
Minor STATUS LED
orange
If minor alarm, monitor the condition.
Switching module
temperature sensor exceeds
major threshold
Major STATUS LED red syslog message and SNMP trap
generated.
Power down the module
4
.
4. See the “Power Management” section on page 22-12 for instructions.
Switching module
temperature sensor exceeds
minor threshold
Minor STATUS LED
orange
syslog message and SNMP trap
generated.
Monitor the condition.
