13-15
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 13 Configuring CEF for PFC2 and PFC3A
Configuring CEF for PFC2/PFC3A on the Switch
Displaying the Layer 3-Switching Entries on the Supervisor Engine
CEF for PFC2/PFC3A is permanently enabled on Supervisor Engine 2 with PFC2 and MSFC2 and on
Supervisor Engine 720 with PFC3A and MSFC3. No configuration is required.
To display all the Layer 3-switching entries on the supervisor engine, perform this task:
This example shows how to display the Layer 3-switching entries:
Console> (enable) show mls entry
Mod FIB-Type Destination-IP Destination-Mask NextHop-IP Weight
--- --------- --------------- ---------------- --------------- ------
15 receive 0.0.0.0 255.255.255.255
15 receive 255.255.255.255 255.255.255.255
15 receive 127.0.0.12 255.255.255.255
16 receive 127.0.0.0 255.255.255.255
16 receive 127.255.255.255 255.255.255.255
15 resolved 127.0.0.11 255.255.255.255 127.0.0.11 1
15 receive 21.2.0.4 255.255.255.255
16 receive 21.0.0.0 255.255.255.255
16 receive 21.255.255.255 255.255.255.255
15 receive 44.0.0.1 255.255.255.255
16 receive 44.0.0.0 255.255.255.255
16 receive 44.255.255.255 255.255.255.255
15 receive 42.0.0.1 255.255.255.255
16 receive 42.0.0.0 255.255.255.255
16 receive 42.255.255.255 255.255.255.255
15 receive 43.0.0.99 255.255.255.255
15 receive 43.0.0.0 255.255.255.255
15 receive 43.255.255.255 255.255.255.255
15 receive 192.20.20.20 255.255.255.255
16 receive 21.2.0.5 255.255.255.255
16 receive 42.0.0.20 255.255.255.255
15 connected 43.0.0.0 255.0.0.0
15 drop 224.0.0.0 240.0.0.0
15 wildcard 0.0.0.0 0.0.0.0
Mod FIB-Type Dest-IPX-net NextHop-IPX Weight
--- --------- ------------ ------------------------- ------
15 connected 21
15 connected 44
15 connected 42
15 resolved 450 42.0050.3EA9.ABFD 1
15 resolved 480 42.0050.3EA9.ABFD 1
15 wildcard 0
Task Command
Display Layer 3-switching information. show mls entry [pbr-route] [cef] | [netflow-route] [qos]
