Downloadable ACLs
7. deny ip host 9.6.6.104 67.104.129.189 255.255.0.0
8. include downloaded-acl dot1x
• Displays the dot1x user all O/P:
Console> (enable) show dot1x user all
Username Mod/Port UserIP VLAN
---------------------- -------- ------ ------
host 5/35 9.6.6.104 16
Downloaded ACL
---------------------------------------------------------
ACSACL#-IP-test-44bb6f49
Derived ACL
--------------------------------
dacl1x_5_35
• Checks the DACL name:
Console> (enable) show security acl downloaded-acl all
Downloaded ACL Summary:
ACL Name Date/Time
-----------------------------------------------------------------------
1.#ACSACL#-IP-test-44bb6f49 Fri Jul 21 2006, 05:05:58
Displays the user-mapped IP, port, and the feature:
Console> (enable) show security acl downloaded-acl user-map
Downloaded ACL User Map:
ACL Name : #ACSACL#-IP-test-44bb6f49
User Count : 1
Num of Aces : 5
Ip Address mNo/pNo Feature
------------------------------------------------------------
1. 9.6.6.104 5/35 dot1x
• Displays the DACL information specific to the port:
Console> (enable) show security acl downloaded-acl port 5/35
Port IP Address Feature Downloaded ACL
----- ---------------- ---------- -------------------------------------
5/35 9.6.6.104 dot1x #ACSACL#-IP-test-44bb6f49
• Displays the ACEs that were downloaded from the RADIUS server:
Console (enable) show security acl downloaded-acl #ACSACL#-IP-test-44bb6f49
Downloaded ACE's for #ACSACL#-IP-test-44bb6f49:
permit ip any 10.76.255.85 255.255.255.0
deny ip any 64.104.129.189 255.255.0.0
permit tcp any eq 21 host 10.76.255.25
deny ip any 6.104.129.189 255.255.0.0
deny ip any 67.104.129.189 255.255.0.0
Configuring a Downloaded ACL for Dot1x for an IP Phone
To configure a downloaded ACL for dot1x with an IP phone, perform these steps:
Step 1 Grant permission for the IP phone by configuring the base-ACL.
Console> (enable) set security acl ip dacl1x permit arp-inspection any any
