Chapter 46 Configuring the Switch Fabric Modules
Configuring and Monitoring the Integrated Switch Fabric and Switch Fabric Module on the Switch
This example shows how to display the integrated switch fabric status and speed:
Console> show fabric status
Mod Speed Fabric
status
--- ----- -------
5 20G active
Console> (enable)
Configuring the LCD Banner
You can modify the LCD banner from the supervisor engine by entering the set banner lcd command to
include the following information:
• Chassis serial number
• Switch IP address
• System name
• Supervisor engine version
• Multilayer Switch Feature Card (MSFC) version on active and standby supervisor engine
• System contact
After the LCD banner content is modified, this information is sent to the Switch Fabric Modules that are
installed in the chassis and displayed in the LCDs.
Note The set banner lcd command is not supported in the systems with an integrated switch fabric.
To modify the LCD banner content, perform this task in privileged mode:
This example shows how to modify the LCD banner for the Switch Fabric Module:
Console> (enable) set banner lcd &HelloWorld!&
LCD banner set
Console> (enable) show banner
MOTD banner:
LCD config:
Hello
World!
Task Command
Step 1
Modify the LCD banner content. set banner lcd c [text] c
Step 2
Verify the LCD banner change. show banner
