52-51
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 52 Configuring QoS
Configuring QoS on the Switch
This example shows how to modify the default IP ACL:
Console> (enable) set qos acl default-action ip dscp 5 microflow my-micro aggregate my-agg
QoS default-action for IP ACL is set successfully.
Console> (enable)
Modifying the Default IP Egress ACL
Note Only PFC3 supports the configuration commands in this section.
To modify the default IP egress ACL, perform this task in privileged mode:
Note In the default egress ACL, the trust-dscp keywords cause the ACL to trust the internal DSCP value, not
a received DSCP value (see the “Internal DSCP Values” section on page 52-16).
For more information, see the “Default ACLs” section on page 52-22.
This example shows how to modify the default IP ACL:
Console> (enable) set qos acl default-action ip dscp 5 microflow my-micro aggregate my-agg
QoS default-action for IP ACL is set successfully.
Console> (enable)
Creating or Modifying the Named IPX ACLs
Note PFC3 does not provide QoS for the IPX traffic. See the “MAC ACE Layer 2 Classification Criteria”
section on page 52-21 for information about how to use the MAC ACLs to filter the IPX traffic.
Task Command
Step 1
Modify the default IP ACL. set qos acl default-action ip {dscp dscp |
trust-dscp} [aggregate aggregate_name] output
Step 2
Verify the configuration. show qos acl info default-action ip
